Axicon Lens
Axicon lens usually called a rotationally symmetric prism and is a axicon lens composed of a conical surface and a flat surface. Axicon lens is often used to generate a beam of Bessel intensity distribution or a conical non-divergent beam. When changing the collimated beam into a ring beam, the plane of the cone lens should face the collimated light source. The light beam generated by the conical lens passes through the optical axis. When the distance from the conical lens to the image increases, the diameter of the formed halo will also increase, while the thickness of the halo remains unchanged. The light beam has the characteristics of a Bessel beam, and the light intensity distribution along the beam propagation direction will not change.
-
GaSe Crystal
Gallium Selenide (GaSe) non-linear optical single crystal, combining a large non-linear coefficient, a high damage threshold and a wide transparency range. It is a is very suitable material for SHG in the mid-IR.
-
ZGP(ZnGeP2) Crystals
ZGP crystals possessing large nonlinear coefficients (d36=75pm/V), wide infrared transparency range(0.75-12μm), high thermal conductivity(0.35W/(cm·K)), high laser damage threshold (2-5J/cm2)and well machining property, ZnGeP2 crystal was called the king of infrared nonlinear optical crystals and is still the best frequency conversion material for high power, tunable infrared laser generation. We can offer high optical quality and large diameter ZGP crystals with extremely low absorption coefficient α < 0.05 cm-1(at pump wavelengths 2.0-2.1 µm), which can be used to generate mid-infrared tunable laser with high efficiency through OPO or OPA processes.
-
AGSe(AgGaSe2) Crystals
AGSe AgGaSe2 crystals have band edges at 0.73 and 18 µm. Its useful transmission range (0.9–16 µm) and wide phase matching capability provide excellent potential for OPO applications when pumped by a variety of different lasers. Tuning within 2.5–12 µm has been obtained when pumping by Ho:YLF laser at 2.05 µm; as well as non-critical phase matching (NCPM) operation within 1.9–5.5 µm when pumping at 1.4–1.55 µm. AgGaSe2 (AgGaSe2) has been demonstrated to be an efficient frequency doubling crystal for infrared CO2 lasers radiation.
-
AGS(AgGaS2) crystals
AGS is transparent from 0.50 to 13.2 µm. Although its nonlinear optical coefficient is the lowest among the mentioned infrared crystals, high short wavelength transparency edging at 550 nm is made use of in OPOs pumped by Nd:YAG laser; in numerous difference frequency mixing experiments with diode, Ti:Sapphire, Nd:YAG and IR dye lasers covering 3–12 µm range; in direct infrared countermeasure systems, and for SHG of CO2 laser. Thin AgGaS2 (AGS) crystal plates are popular for ultrashort pulse generation in mid IR range by difference frequency generation employing NIR wavelength pulses.
-
BGSe(BaGa4Se7) Crystals
High-quality crystals of BGSe (BaGa4Se7) is the selenide analogue of the chalcogenide compound BaGa4S7, whose acentric orthorhombic structure was identified in 1983 and the IR NLO effect was reported in 2009, is a newly developed IR NLO crystal. It was obtained via the Bridgman–Stockbarger technique. This crystal exhibits high transmittance over the wide range of 0.47–18 μm, except for an absorption peak at around 15 μm.
-
