Plano-Concave Lenses

Plano-concave lens is the most common item used for light projection and beam expansion. Coated with antireflective coatings, lenses are used in various optical systems, lasers and assemblies.

Material: BK7, FS, UVFS, CaF2, ZnSe, Si, Ge

Wavelength: 350-2000nm/185-2100nm

Dimension Tolerance: +0.0/-0.1mm

Clear Aperture: >85%

Focal Length Tolerance: 5%(Standard)/ 1%(High Precision)

WhatsApp Send email to us Download as PDF

Product Detail

Technical Parameters

Plano-concave lens is the most common item used for light projection and beam expansion. Coated with antireflective coatings, lenses are used in various optical systems, lasers and assemblies.

Material	BK7, FS, UVFS, CaF2, ZnSe, Si, Ge
Wavelength	350-2000nm/185-2100nm
Dimension Tolerance	+0.0/-0.1mm
Thickness Tolerance	+/-0.1mm
Clear Aperture	>85%
Focal Length Tolerance	5%(Standard)/ 1%(High Precision)
Surface Quality	40/20(Standard)/ 20/10(High Precision)
Centration	<3 arc min
Coating	Upon customers’ request
