• Factory source – Er: YAG Crystals – Dien

    Factory source – Er: YAG Crystals – Dien

    Er: YAG is a kind of excellent 2.94 um laser crystal, widely used in laser medical system and other fields. Er: YAG crystal laser is the most important material of 3nm laser, and the slope with high efficiency, can work at room temperature laser, laser wavelength is within the scope of the human eye safety band, etc. 2.94 mm Er: YAG laser has been widely used in medical field surgery, skin beauty, dental treatment. Advantages of Er:YAG Crystals: • High slope efficiency • Operate well at room ...
  • 18 Years Factory Custom Optics - TGG Crystals – Dien

    18 Years Factory Custom Optics - TGG Crystals – Dien

    TGG is an excellent magneto-optical crystal used in various Faraday devices (Rotator and Isolator) in the range of 400nm-1100nm, excluding 475-500nm. Advantages of TGG: Large Verdet constant (35 Rad T-1 m-1) Low optical losses (<0.1%/cm) High thermal conductivity (7.4W m-1 K-1). High laser damage threshold (>1GW/cm2)
  • One of Hottest for Beauty Lamp - LiB3O5(LBO) Crystal – Dien

    One of Hottest for Beauty Lamp - LiB3O5(LBO) Crystal – Dien

    LBO (Lithium Triborate – LiB3O5) is now the most popularly used material for Second Harmonic Generation (SHG) of 1064nm high power lasers (as a substitute to KTP) and Sum Frequency Generation (SFG) of 1064nm laser source to achieve UV light at 355nm. LBO is phase matchable for the SHG and THG of Nd:YAG and Nd:YLF lasers, using either type I or type II interaction. For the SHG at room temperature, type I phase matching can be reached and has the maximum effective SHG coefficient in the p...
  • OEM/ODM China Bbo Shg - AgGaGe5Se12 Crystals – Dien

    OEM/ODM China Bbo Shg - AgGaGe5Se12 Crystals – Dien

    ZGP crystals possessing large nonlinear coefficients (d36=75pm/V), wide infrared transparency range(0.75-12μm), high thermal conductivity(0.35W/(cm·K)), high laser damage threshold (2-5J/cm2)and well machining property, ZnGeP2 crystal was called the king of infrared nonlinear optical crystals and is still the best frequency conversion material for high power, tunable infrared laser generation. We can offer high optical quality and large diameter ZGP crystals with extremely low absorption coef...
  • Factory wholesale Ir Crystal - KTA  Crystal – Dien

    Factory wholesale Ir Crystal - KTA Crystal – Dien

    Potassium Titanyle Arsenate (KTiOAsO4), or KTA crystal, is an excellent nonlinear optical crystal for Optical Parametric Oscillation (OPO) application. It has better non-linear optical and electro-optical coefficients, significantly reduced absorption in the 2.0-5.0 µm region, broad angular and temperature bandwidth, low dielectric constants. And its low ionic conductivities  result in higher damage threshold compared with KTP . KTA is often used as an OPO / OPA gain medium for emission in th...
  • Chinese wholesale – BIBO Crystal – Dien

    Chinese wholesale – BIBO Crystal – Dien

    BiB3O6 (BIBO) is a newly developed nonlinear optical crystal. It possesses large effective nonlinear coefficient, high damage threshold and inertness with respect to moisture. Its nonlinear coefficient is 3.5 – 4 times higher than that of LBO, 1.5 -2 times higher than that of BBO. It is a promising doubling crystal to produce blue laser. BiB3O6 (BIBO) is an excellent kind of nonlinear Optical Crystal. NLO Crystals BIBO Crystals possesses large effective nonlinear coeffcient, wide advanc...
